5x60W Retro LED Matrix Bar - Tungsten Golden Beam Blinder with RGB Halo Rings & Pixel Wash Strip for DJ, TV Stage & Concerts

Bring the perfect blend of classic aesthetics and modern technology to your stage with the 5x60W Retro LED Matrix Bar. This fixture combines the warm vintage punch of a tungsten-style golden beam blinder with modern RGB LED halo rings and continuous RGB pixel wash strips.

Designed for DJs, TV broadcasts, live concerts, clubs, and stage productions, this retro matrix bar delivers powerful 800W illumination in a heavy-duty metal body. With point-by-point pixel control, DMX512 operation, sound mode, auto mode, and master-slave control, lighting designers can combine old-school blinder warmth with modern RGB chase effects for dynamic stage backdrops.

Key Features

• Retro Tungsten-Style Output: Features 5 x 60W LED golden light beads with high-definition lenses for a classic warm blinder effect.
• RGB Eye-Candy Effects: RGB LED halo rings around each lens plus continuous RGB wash strips create layered color effects and chase visuals.
• Point-by-Point Control: Main beams and auxiliary RGB sections can be pixel-mapped for custom chase sequences and dynamic patterns.
• Wash & Strobe Effects: Supports wash, strobe, and pixel-style effects for stage backgrounds, DJ booths, and live event environments.
• Heavy-Duty Metal Body: Corrosion-resistant metal housing is built for stable stage use and repeated event setups.
• High-Power Cooling Fans: Large-air-volume fan cooling helps dissipate heat and protect the high-brightness LEDs during operation.
• Simple Digital Display: Onboard display allows parameter adjustment, addressing, and mode selection.
• Versatile Control Modes: Supports DMX512, sound, auto, and slave operation modes.

Instructions

1. Mounting: Use the reinforced bracket handles to mount the fixture to a suitable truss system or place it securely on a stable stage surface. Make sure the fixture is balanced and properly secured before use.
2. Power Setup: Connect the fixture to a reliable 110–220V, 50/60Hz power source. Since the fixture has an 800W power supply, confirm that the circuit and power distribution setup can safely handle the connected load.
3. Data Connection: Connect your lighting console through the DMX input/output ports. Use the digital display panel to assign the DMX address and select the desired channel mode.
4. Programming: Use DMX control to combine golden blinder beams with RGB halo rings and RGB wash strips. Built-in effects can be used for quick shows, while point-by-point programming can create customized stage looks.
5. Standalone Operation: For simpler setups, use sound mode, auto mode, or slave mode for built-in dynamic effects without full DMX programming.
6. Maintenance: Keep the cooling fans, ventilation slots, lenses, rings, and wash strip areas clean and free from dust or debris to maintain proper heat dissipation and visual output.

Technical Specifications
