1200W IP65 Outdoor Architectural LED Wash Light - Heavy Duty Dual-Panel Wall Washer Flood Light (120x10W RGBW) for Building Facades & Stadiums

The 1200W IP65 Outdoor Architectural LED Wash Light is a heavy-duty dual-panel wall washer and flood light designed for building facades, stadiums, warehouses, outdoor stages, and large-scale architectural environments. Equipped with 120 x 10W RGBW 4-in-1 LEDs, it delivers powerful full-color wash output with an effect distance of up to 60 meters.

Built with a rugged aluminum alloy housing and IP65 waterproof protection, this City Color-style fixture is designed for reliable outdoor use. With 40° beam coverage, 0–100% dimming, 1–20 times strobe, DMX512 control, 8CH / 16CH modes, master-slave operation, and self-propelled mode, it gives lighting professionals strong control for architectural washes, stadium lighting, and large outdoor event effects.

Key Features

• High-Power RGBW Output: Features 120 x 10W RGBW 4-in-1 LEDs for intense full-color wash lighting and bright outdoor illumination.
• Long-Range Projection: Designed with a 40° beam angle and up to 60m effect distance for building facades, stadiums, and large exterior surfaces.
• IP65 Outdoor Protection: Waterproof aluminum alloy housing supports outdoor architectural and event use when installed correctly.
• Smooth Dimming & Strobe: Supports 0–100% dimming and 1–20 times strobe effects for dynamic lighting transitions.
• Flexible Control Modes: Supports DMX512 signal, master-slave operation, and self-propelled mode.
• 8CH / 16CH Control: Choose 8-channel or 16-channel mode depending on your color, dimming, and strobe programming needs.
• Durable Aluminum Alloy Body: Heavy-duty housing supports demanding outdoor installations and touring applications.
• Architectural Wash Design: Suitable for large walls, parks, buildings, stadiums, warehouses, and outdoor stage backdrops.

Instructions

1. Installation & Rigging: Due to the heavy-duty design, mount the fixture only on a robust architectural surface, truss, or ground base that can safely support the 38 kg net weight and the dual-panel structure.
2. Power Connection: Connect the fixture to a compatible power supply. The fixture supports AC100–240V 50/60Hz, with AC90–140V / AC190–240V options depending on local standards.
3. DMX Configuration: Connect your DMX cables and assign the DMX address through the control interface. Select 8CH or 16CH mode based on the level of color and strobe control required.
4. Operation: Use a DMX controller for programmed architectural lighting effects, or use self-propelled / master-slave modes for standalone or synchronized multi-fixture operation.
5. Outdoor Use: Before outdoor operation, confirm that all power and data ports are properly sealed and protected to help maintain the IP65 waterproof rating.
6. Maintenance: Keep the front lenses, housing, seals, brackets, and connector areas clean. Inspect waterproof seals regularly to maintain light output and outdoor reliability.
