1000W IP65 Motorized Hybrid LED Strobe Light - Moving Head Wash & Blinder with RGBW Pixel Control & Tilt for Outdoor Concerts & Festivals

The 1000W IP65 Motorized Hybrid LED Strobe Light is a powerful outdoor stage fixture designed for large-scale concerts, music festivals, touring productions, clubs, and high-energy event environments. Built with a rugged die-cast aluminum alloy shell and IP65 waterproof protection, this fixture is designed to handle demanding indoor and outdoor applications.

This hybrid fixture combines a high-density RGB LED strobe panel with bright white LED strobe tubes, creating a flexible wash, blinder, and strobe effect in one unit. With 1000W rated power, motorized tilt up to 185°, RGB and white LED segment control, 0–100% linear dimming, electronic strobe up to 20Hz, DMX512, RDM, master-slave, self-propelled, and sound control modes, it gives lighting designers strong creative control for festival stages and large event productions.

Key Features

• Massive 1000W Output: Delivers powerful hybrid wash, blinder, and strobe effects for large venues, festivals, and outdoor stages.
• Hybrid LED Matrix: Combines 504 pcs 0.5W 5050 RGB Tri-LEDs with 96 x 5W white LEDs for both rich color effects and intense white strobe output.
• Segment Control: RGB LEDs are divided into 16 segments, while white LEDs are divided into 4 segments for pixel-style programming and chase effects.
• Motorized Tilt: Tilt movement up to 185° allows dynamic sweeping effects and wider stage coverage.
• Smooth Dimming & Strobe: 0–100% linear dimming with variable curves and electronic strobe up to 20Hz for high-impact flashes and clean transitions.
• IP65 Outdoor Rating: Waterproof design supports outdoor stage and festival use when all power and data connections are properly sealed.
• Multiple Control Modes: Supports DMX512, RDM, master-slave, self-propelled, sound control, gradual, and saltus step effects.
• Professional Rigging Hardware: Includes Omega-bracket support and foldout eyelets for safety wire installation.

Instructions

1. Mounting: Use the Omega brackets for horizontal or vertical installation. Always secure the fixture with proper clamps, foldout eyelets, and safety wire. Make sure the rigging structure can safely support the 12.5 kg net weight.
2. Power & Data: Connect the fixture to a compatible AC110–240V, 50–60Hz power source. Connect DMX cables if using a lighting console or linked stage setup.
3. Configuration: Use the digital display and operation buttons to set the DMX address, select channel mode, or run built-in test programs such as full function testing, LED testing, or tilt testing.
4. DMX Programming: Choose 6CH, 19CH, 82CH, or 99CH mode depending on the control detail required. Use higher channel modes for more advanced RGB and white segment control.
5. Outdoor Use: Before outdoor operation, confirm all power, DMX, and unused connectors are properly sealed and protected to help maintain the IP65 rating.
6. Maintenance: Keep lenses, LED panels, vents, cooling fans, housing, brackets, safety points, and connector areas clean and free from dust or debris. Maintain airflow around the fixture for proper heat dissipation.
